China High Pressure 316L 317L 321 Schedule Stainless Steel Pipe Schedule

Product Description

Type	Stainless Steel Decorative pipe/tube
Material	304 304L 316 316L 316Ti 321 309S 310S 317L 347H 2205 2507 904L
Thinckness	1.73mm-59.54mm
Outer diameter	10.3mm-1219.0mm
Length	6m or as customer's requirement
Finish	Polished, Pickled,hairline,mirror
Shape	Round,square, rectangular,oval
Technology	Seamless,weld
Standard	JIS, AISI, ASTM, GB, DIN, EN ,etc.
MOQ	1Ton
Application	Decoration, industry, etc.
Certificate	SGS
Packaging	Standard exporting packing

Specifications of stainless steel decorative pipe
Standard		0.6	0.7	0.8	0.9	1	1.2	1.5	2	2.5	3	3.5	4	4.5
Actual		0.32	0.4	0.5	0.6	0.7	0.9	1.1	1.4	1.9	2.4	2.9	3.4	3.9
Φ	12.3	0.57	0.71	0.88	1.05	1.21	1.53	1.84
Φ	12.7	0.59	0.74	0.91	1.09	1.26	1.91	1.91
Φ	15.3	0.72	0.89	1.11	1.32	1.53	2.33	2.33
Φ	16	0.75	0.93	1.16	1.38	1.6	2.45	2.45	3.06
Φ	17.2	0.81	1	1.25	1.49	1.73	2.19	2.65	3.31
Φ	18	0.85	1.05	1.31	1.56	1.81	2.3	2.78	3.47
Φ	19	0.89	1.11	1.38	1.65	1.91	2.43	2.94	3.68	4.86
Φ	20.2	0.95	1.18	1.47	1.76	2.04	2.6	3.14	3.93	5.2
Φ	22	1.04	1.29	1.61	1.92	2.23	2.84	3.43	4.31	5.71
Φ	25	1.18	1.47	1.83	2.19	2.54	3.24	3.93	4.94	6.56
Φ	28	1.32	1.65	2.06	2.46	2.86	3.65	4.42	5.57	7.41
Φ	29.2	1.38	1.72	2.14	2.57	2.98	3.81	4.62	5.82	7.75
Φ	31.8	1.51	1.88	2.34	2.8	3.25	4.16	5.04	6.36	8.49	10.55	12.53
Φ	35.8	1.7	2.12	2.64	3.16	3.67	4.69	5.7	7.2	9.63	11.98	14.26
Φ	38	1.8	2.25	2.8	3.35	3.9	4.99	6.07	7.66	10.25	12.77	15.22
Φ	42		2.49	3.1	3.71	4.32	5.52	6.72	8.5	11.39	14.21	16.95
Φ	48		2.85	3.55	4.25	4.95	6.34	7.71	9.75	13.09	16.36	19.55
Φ	50.8		3.01	3.76	4.5	5.24	6.71	8.17	10.34	13.89	17.36	20.76	24.09
Φ	60		3.56	4.45	5.33	6.2	7.95	9.68	12.26	16.5	20.66	24.75	28.77
Φ	63			4.67	5.6	6.52	8.35	10.18	12.89	17.35	21.74	26.05	30.29
Φ	70				6.22	7.25	9.29	11.32	14.36	19.34	24.25	29.09	33.85
Φ	76				6.76	7.88	10.1	12.31	15.61	21.04	26.4	31.69	36.9	42.03
Φ	80				7.12	8.3	10.64	12.97	16.45	22.18	27.84	33.42	38.93	44.36
Φ	85				7.57	8.82	11.31	13.79	17.49	23.6	29.63	35.59	41.47	47.28
Φ	88.9				7.92	9.23	11.84	14.43	18.31	24.71	31.03	37.28	43.45	49.55
Φ	101.6				9.06	10.56	13.55	16.52	20.97	28.32	35.59	42.78	49.91	56.96
Φ	108					11.23	14.41	17.58	22.31	30.13	37.88	45.56	53.16	60.69
Φ	114					11.86	15.21	18.56	23.56	31.84	40.04	48.16	56.21	64.18
Φ	127						16.96	20.7	26.28	35.53	44.7	53.8	62.82	71.76
Φ	133						17.77	21.69	27.54	37.23	46.85	56.4	65.87	75.26
Φ	141						18.85	23	29.21	39.51	49.72	59.86	69.93	79.92
Φ	159							25.96	32.98	44.62	56.18	67.67	79.08	90.42
Φ	168								34.86	47.17	59.41	71.57	83.65	95.66
Φ	219								45.54	61.66	77.7	93.68	109.57	125.39
Standard		0.6	0.7	0.8	0.9	1	1.2	1.5	2	2.5	3	3.5	4	4.5
Actual		0.32	0.4	0.5	0.6	0.7	0.9	1.1	1.4	1.9	2.4	2.9	3.4	3.9

Specifications of stainless steel decorative square pipe
Standard				0.6	0.7	0.8	0.9	1	1.2	1.5	2	2.5	3	3.5	4	4.5
Actual				0.32	0.4	0.5	0.6	0.7	0.9	1.1	1.4	1.9	2.4	2.9	3.4	3.9
Φ	10	×	10	0.59	0.74	0.91	1.09	1.26	1.59	1.91
Φ	12.7	×	12.7	0.76	0.69	1.17	1.4	1.62	2.06	2.48
Φ	15	×	15	0.9	1.12	1.39	1.66	1.93	2.45	2.96
Φ	19	×	19	1.14	1.42	1.77	2.12	2.46	3.13	3.8	4.77	6.33
Φ	20	×	20	1.2	1.5	1.87	2.23	2.59	3.31	4.01	5.04	6.69
Φ	22	×	22	1.32	1.65	2.06	2.46	2.86	3.65	4.43	5.57	7.42
Φ	25	×	25	1.51	1.88	2.34	2.8	3.26	4.16	5.06	6.37	8.5
Φ	28	×	28	1.69	2.11	2.63	3.14	3.66	4.68	5.68	7.17	9.59	11.93
Φ	30	×	30	1.81	2.26	2.82	3.37	3.92	5.02	6.1	7.7	10.31	12.84
Φ	36	×	36		2.72	3.39	4.06	4.72	6.05	7.36	9.3	12.48	15.58
Φ	38	×	38		2.87	3.58	4.29	4.99	6.39	7.78	9.83	13.2	16.5	19.72	22.86

Jiangsu Taigang Puxin Stainless Steel Co., Ltd. is located in Wuxi, Jiangsu, adjacent to Shanghai, with convenient transportation. It was established in 2010 with a registered capital of 20 million yuan and currently employs nearly 100 people. The company specializes in the production of stainless steel plates, stainless steel tubes, stainless steel rods and other stainless steel profiles. In addition, it also produces various alloy plates. The main materials of the company's products are TP304/304L, TP316/316L, TP321, 310S, 904L, S31803, 2520Si2, Monel400, etc. The company has an annual output of more than 10,000 tons of various stainless steel products, which are mainly used in petroleum, chemical, shipbuilding, construction, decoration, semiconductors, automobile engines, locomotive brake systems, gas equipment manufacturing, instrumentation equipment, food processing, catering, brewing and other industries .
High Pressure 316L 317L 321 Schedule Stainless Steel Pipe Schedule

Q1. Where is your factory ?
A1: Our company's processing center is located in Jiangsu, Wuxi, China.
Which is well equipped with kinds of machines, such as laser cutting machine,mirror polishing machine and so on.
We can provide a wide range of personalized services according to the customers' needs.

Q2. What are your company's main products ?
A2: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q3. How do you control quality ?
A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.

Q4. What are the advantages of your company ?
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q5. How many coutries you already exported ?
A5: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt,Turkey, Jordan, India, etc.

Q6. Can you provide sample ?
A6: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7days.
